Plastic ID 4442 Chip Magnetic Stripe Card
1. NFC near field communication technology is a non-contact radio
frequency identification (RFID) and integrated evolved,
interconnection technology, combining induction card reader, on a
single chip inductor CARDS and point to point function, can be in
identification and data exchange with compatible devices over short
distances;
2. Working frequency of 13.56 MHz. But the user must use the mobile
payment solutions to replace special mobile phone;
3. At present the technology is widely used in Japan and South
Korea.Mobile phone users with configuration pay phones can traveled
across the country: their mobile phone can be used as the airport
boarding validation, building, transportation IC card, credit card,
payment card of entrance guard key and so on.
4. Smart card can be pvc card, prepaid card, plastic card, scratch
card, id card, access control, card, rfid card, card, contactless
card, business cards, gift card, membership card, greeting cards,
RFID, hotel key card, chip card, rfid smart cards, barcode card,
rfid smart card, contactless ic card, greeting card, FRID, vip card
ect.
| Item name | Factory price blank pvc card with chip in credit size |
| Material: | PVC/PET/ABS/Plastic,etc |
| Size: | 85.5mm * 54mm (ISO CR-80 Standard)/Can be Customized |
| Thickness: | From 0.5mm to 1mm, standard thickness 0.76mm |
| Minimum QTY: | 1000pcs |
| Processing: | 4 color offset printing,embossing number, signature panel, photo,
Barcode , gold / sliver color, scratch-off, series number,
hole punching, spot UV printing, hologram, etc. |
| Applications: | Restaurants,clubs, casinos, beauty parlors, cakes & pastry shops,
medical clinics, fitness centers, photography & camera shops, etc. |
| Payment terms: | By T/T or Western Union. 100% full advance payment of the total
amount
before production. |
| Production time: | 8-12 working days after receipt of 100% advance payment (below
50,000pcs) |
| Delivery: | By sea or air express |
| Packaging: | For standard size cards:
Inner box: 22.5 * 9.3 * 6cm (250pcs / per box)
Carton: 52.5* 22.5 * 15cm (5,000pcs / per carton) |
| Certification: | ISO/ ROHS/ SGS |
1. NFC is only limited to 13.56 MHz band! And RFID frequency has a
low frequency (125 KHZ to 135 KHZ), high frequency (13.56 MHz) and
ultra high frequency (868 MHz to 928 MHz.)
2. Smart card work range: NFC (less than 10 cm, so has the very
high security), RFID distance from several meters to tens of
meters!
3. For the same work at 13.56 MHz, NFC compatible with existing
contactless smart card technology, so a lot of manufacturers and
related groups support NFC, and RFID standard, unified complex
(uniform) estimation is not possible, only under the special
industries with special needs, the corresponding technical
standards!
4. Application: RFID more be applied on the production, logistics,
tracking, asset management, while NFC in areas such as access
control, bus, mobile payment plays a huge role.
Smart card chip option:
The chip type that works best for you, is often determined by what
you want to write to the Smart Card. Date is measures in bytes. The
chip type and date size for each product is listed in the Excel
Sheet below:
| Factory | Model number | Specification |
| SIEMENS | SLE5542(4442) | 256 bit |
| SLE5528(4428) | 1024*8 bit |
| Shanghai Fudan | FM4442 | 256 bit |
| FM24C16 | 16K bit |
| FM5528 | 1024 bit |
| Shanghai Belling | BL7442 | 256 bit |
| BL24C04 | 4K bit |
| ISSI | ISSI4442 | 256 bit |
| ISSI24C16 | 16 Kbit |
| ISSI4428 | 8 Kbit |
| ATMEL | AT24C01 | 1K bit(stop production) |
| AT24C02 | 2K bit |
| AT24C04 | 4K bit |
| AT24C16 | 16K bit |
| AT88SC102 | 1K bit |
